BaiCells sBS77410 Nova452 Outdoor LTE TDD eNodeB Base Station, Band 41, 4×40 W

The BaiCells sBS77410 Nova452 is an outdoor LTE TDD eNodeB base station designed for wireless broadband infrastructure. It is intended for network operators and service providers deploying LTE access networks in the supported frequency range.

The Band 41 model operates from 2496 to 2690 MHz and uses a 4T4R radio configuration with four 40 W transmit paths. The system supports external antennas and a 48 V DC power input.

LTE Radio Performance

The Nova452 supports LTE TDD technology and a two-carrier architecture. Depending on the deployment configuration, it can operate in carrier aggregation (CA) mode or dual-carrier (DC) mode.

In carrier aggregation mode, the base station supports two-component-carrier downlink and uplink aggregation. This allows compatible network configurations to combine two carriers for increased peak throughput relative to a single carrier.

In dual-carrier mode, the carriers operate as independent cells, allowing the equipment to support separate cell deployments. Actual capacity and performance depend on spectrum allocation, radio configuration, network planning, and software capabilities.

Outdoor Hardware and Antenna Connectivity

The sBS77410 is designed for outdoor installation and has an IP66 ingress protection rating. The enclosure is intended to protect the equipment against dust and powerful water jets when installed according to the manufacturer's requirements.

The base station uses external antennas and supports pole- or wall-mounted installation. Antenna selection, feeder losses, mounting hardware, grounding, and lightning protection should be planned for the specific deployment.

Power and Installation

The Nova452 requires 48 V DC power. The datasheet specifies typical power consumption of 520 W and maximum power consumption of 560 W. The power system should be sized for the equipment's documented electrical requirements and the applicable installation conditions.

The manufacturer installation guide should be followed for mounting, electrical connections, grounding, antenna connections, and commissioning. Installation should be performed by personnel with appropriate telecommunications and electrical experience.

Network Deployment and Compatibility

The sBS77410 is intended for LTE Band 41 network deployments. Its use requires compatible radio planning, supported spectrum, appropriate antennas, and compatible network software and infrastructure.

Although the Nova452 platform is described as hardware-ready for New Radio (NR) 5G technology, this should not be interpreted as confirmation that every 5G feature or configuration is enabled on a specific unit. Confirm software version, licensing, and deployment requirements with BaiCells before purchasing for a particular network.

1. Key Features

• Outdoor LTE base station: Nova452 TDD eNodeB for compatible wireless broadband networks.

• LTE Band 41: Supports the 2496–2690 MHz frequency range.

• 4T4R radio configuration: Four transmit and four receive paths.

• High-power radio: Four 40 W transmit paths.

• Carrier aggregation: Supports two-component-carrier downlink/uplink carrier aggregation.

• Dual-carrier operation: Supports two independently operated carriers in the documented dual-carrier mode.

• External antenna support: Designed for connection to external antennas.

• 48 V DC power: Requires an appropriate compatible DC power system.

• Outdoor-rated enclosure: IP66 ingress protection rating.

• Pole or wall installation: Supports outdoor mounting using the appropriate installation hardware.

2. Technical Specifications

3. Applications / Use Cases

• Outdoor LTE broadband network infrastructure.

• LTE Band 41 fixed wireless access networks.

• Wireless broadband service provider deployments.

• LTE TDD radio access networks.

• Two-carrier LTE deployments using carrier aggregation.

• Independent dual-carrier cell deployments.

• Outdoor network expansion where supported LTE spectrum is available.

4. Compatibility

The BaiCells sBS77410 is intended for deployments that meet the following requirements:

• Frequency compatibility: The network must support LTE Band 41 within the 2496–2690 MHz range.

• Antenna compatibility: External antennas must be appropriate for the operating band, radio configuration, and installation requirements.

• Power compatibility: The installation must provide a suitable 48 V DC power system capable of supporting the documented power demand.

• Network compatibility: Confirm interoperability with the intended LTE core, network management system, software release, and existing radio infrastructure.

• Carrier aggregation: Two-carrier operation requires compatible spectrum assignments and appropriate network configuration.

• Installation compatibility: Pole or wall mounting must follow the manufacturer's installation requirements.

Important: The sBS77410 is the Band 41 variant. The Nova452 family also includes other band-specific models. Do not substitute a Band 40 or Band 42 variant without confirming the deployment requirements.

5. What's Included

Package contents for the exact sBS77410 SKU have not been confirmed in the available official documentation.

Before publishing this section, verify whether the supplied unit includes mounting hardware, power cables, antenna cables, grounding accessories, or other installation components. Do not assume external antennas or a power supply are included.

6. Frequently Asked Questions

Q1. What is the BaiCells sBS77410?

It is the BaiCells Nova452 outdoor LTE TDD eNodeB base station designed for Band 41 wireless broadband infrastructure.

Q2. Which frequency band does the sBS77410 support?

The manufacturer specifies LTE Band 41, covering 2496–2690 MHz.

Q3. What does the 4×40 W specification mean?

The product is specified with four 40 W transmit paths. This is a radio transmit-power configuration, not a statement of guaranteed user throughput.

Q4. Does the Nova452 support carrier aggregation?

Yes. The manufacturer documents two-component-carrier downlink and uplink carrier aggregation, as well as a dual-carrier operating mode.

Q5. What power supply does the base station require?

The documented DC input is 48 V. Typical power consumption is 520 W, with a maximum of 560 W. Confirm the power-system requirements before installation.

Q6. Is the sBS77410 suitable for outdoor installation?

Yes. It has an IP66 ingress protection rating and supports pole or wall mounting when installed according to the manufacturer's instructions.

Q7. Are antennas and mounting accessories included?

Package contents have not been confirmed for the specific SKU. Check the supplier's quotation or packing list before ordering.

Q8. Can Multilink Solutions help verify compatibility?

Yes. Contact Multilink Solutions for assistance reviewing Band 41 compatibility, antenna requirements, power specifications, and network deployment needs before purchase.

7. Why Buy from Multilink?

Multilink Solutions supports businesses sourcing networking and wireless broadband infrastructure equipment.

• Product sourcing: Assistance identifying the correct BaiCells model for your deployment.

• Quotation assistance: Request a quote for the Nova452 sBS77410.

• Technical specification review: Help reviewing frequency, radio configuration, power requirements, and environmental specifications.

• Compatibility assistance: Support checking the intended network configuration and related infrastructure.

• Model identification: Help distinguishing Band 41 from other Nova452 variants.
