BaiCells PBS3101S Nova430i Outdoor LTE TDD eNodeB Base Station, Band 48, Integrated Antenna

The BaiCells PBS3101S Nova430i is an outdoor LTE TDD eNodeB designed for public and private wireless broadband networks. Its integrated antenna design combines four 250 mW transmit channels with LTE radio functionality in a single outdoor unit.

The standard PBS3101S configuration operates in LTE TDD Band 48 (3550–3700 MHz) and supports LTE 3GPP Release 15. It offers Carrier Aggregation (CA) and Dual Carrier (DC) operating modes, GPS synchronization, Ethernet backhaul, and PoE++ power.

The Nova430i supports local and remote web management, Self-Organizing Network (SON) functions, and interoperability with standard LTE Evolved Packet Core (EPC) systems. BaiCells also documents HaloB as an embedded EPC option. Its IP65-rated enclosure and pole- or wall-mount installation make it suitable for appropriately engineered outdoor deployments.

Important: This is an LTE base station, not a conventional Wi-Fi router. Confirm the frequency variant, LTE core-network compatibility, spectrum authorization, and included power and mounting accessories before deployment.

1. Key Features

• Outdoor LTE TDD eNodeB base station

• BaiCells Nova430i product family

• LTE 3GPP Release 15

• Four 250 mW transmit channels (24 dBm per channel)

• Standard configuration: Band 48, 3550–3700 MHz

• Built-in high-gain LTE antenna array

• Antenna gain: 13 ± 1 dBi

• Carrier Aggregation (CA) and Dual Carrier (DC) operation

• Channel bandwidths of 5, 10, 15, and 20 MHz per carrier

• 2×2 downlink MIMO per carrier

• One RJ-45 Fast/Gigabit Ethernet interface

• PoE++ power compliant with IEEE 802.3bt

• GPS synchronization

• Local and remote web management

• IP65-rated enclosure

• Pole or wall mounting

2. Technical Specifications

3. Applications / Use Cases

• Outdoor private LTE networks

• Public wireless broadband infrastructure

• Expanding LTE coverage in targeted service areas

• Enterprise and industrial wireless connectivity

• Fixed wireless access deployments using compatible LTE customer-premises equipment

• Deployments using Carrier Aggregation or Dual Carrier configurations

Actual coverage and performance depend on the environment, antenna characteristics, spectrum configuration, interference, and connected equipment.

4. Compatibility

Before purchasing or installing the PBS3101S, confirm:

• Frequency compatibility: The standard model is Band 48, 3550–3700 MHz. Verify any customized Band 42/43 unit separately.

• LTE core network: The base station must be compatible with the network's EPC and configuration.

• Subscriber equipment: CPEs and other LTE devices must support the deployed frequency band.

• Power: Use a compatible PoE++ source that meets the manufacturer's requirements.

• Backhaul: Provide suitable Ethernet connectivity and network security.

• Installation: Ensure the pole or wall mounting arrangement meets the installation guide.

• Regulatory approval: Confirm that the exact unit is authorized for use in the intended market.

5. Frequently Asked Questions

Q1. What is the BaiCells PBS3101S?
It is the Nova430i outdoor LTE TDD eNodeB base station with an integrated LTE antenna array.

Q2. Which frequency band does it support?
The standard PBS3101S model is specified for Band 48, 3550–3700 MHz. Customized variants may differ.

Q3. Does it have a built-in antenna?
Yes. BaiCells specifies a built-in high-gain LTE antenna array.

Q4. Does it support PoE++?
Yes. The manufacturer specifies PoE++ compliant with IEEE 802.3bt. Confirm whether power equipment is included in your shipment.

Q5. What is its maximum data rate?
BaiCells documents peak rates of up to 290 Mbps downlink and 70 Mbps uplink for a specified 2 × 20 MHz configuration. Actual throughput depends on the operating mode and network configuration.

Q6. Is it designed for outdoor installation?
Yes. The manufacturer lists an IP65 ingress protection rating and an operating temperature range of -40°C to 55°C.

Q7. What are the product dimensions and weight?
319 × 227 × 104 mm and 4.85 kg without the mounting bracket. These are product measurements, not package measurements.

Q8. What warranty does it have?
Manufacturer documentation states a one-year warranty. Confirm the current warranty terms for your specific stock.
