BaiCells EG2011B-M3 Atom ID06 Indoor LTE CPE, Band 41, Wi-Fi

The BaiCells EG2011B-M3 Atom ID06 is an indoor LTE customer-premises equipment device designed to deliver broadband data and voice services over compatible LTE TDD networks. Its integrated LTE radio, Wi-Fi access point, Ethernet interface, and telephone port combine multiple connectivity functions in one device.

The EG2011B-M3 is the 2.5 GHz Band 41 version identified in the BaiCells Atom ID06 datasheet. It is intended for indoor customer-premises deployments where the local LTE network supports the device's frequency configuration.

LTE Connectivity and Performance

The EG2011B-M3 belongs to the Atom ID06 LTE Cat 6/7 platform and supports LTE TDD operation. The manufacturer datasheet specifies channel bandwidths of 5, 10, 15, and 20 MHz and lists support for two-component-carrier aggregation at the platform level.

The datasheet lists a peak LTE data rate of up to 220 Mbps downstream and 15 Mbps upstream for a 20 MHz configuration under the stated TDD conditions. These are manufacturer-specified peak figures, not guaranteed real-world speeds. Actual performance depends on the LTE network, spectrum configuration, signal quality, congestion, and service plan.

The integrated internal LTE antenna is specified at 5 dBi gain for the 2.5 GHz model.

Wi-Fi and Wired Networking

The built-in Wi-Fi access point supports IEEE 802.11b/g/n in the 2.4 GHz band. The manufacturer lists a maximum theoretical Wi-Fi rate of 300 Mbps for 802.11n, depending on the configuration and wireless conditions.

One RJ45 Ethernet port supports 10/100/1000 Mbps wired connectivity for compatible computers, switches, and other Ethernet devices.

Voice and Telephone Connectivity

The EG2011B-M3 includes one RJ11 POTS interface. The Atom ID06 platform supports VoIP-related functions, including dual-APN operation, SIP ALG, G.711 fax pass-through, and T.38 fax relay, as documented by the manufacturer.

Voice service availability depends on the service provider, network configuration, and enabled firmware features. Confirm voice-service compatibility before deployment.

Management and Security

The device provides local and remote web-based management. The manufacturer documents NAT and bridge network modes, IPv4/IPv6 support, SIM PIN management, SIM locking, and LTE scan or frequency-lock options.

Additional documented platform features include firewall filtering, access controls, port forwarding, DMZ, VPN support, diagnostic tools, status monitoring, configuration backup and restore, and firmware upgrades. Some management functions depend on firmware version and service-provider configuration.

Installation and Power

The Atom ID06 is designed for indoor use. Its manufacturer-documented dimensions are 193 × 168 × 74 mm, with a device weight of approximately 400 g.

The datasheet specifies a universal 100–240 V AC input power adapter with a 12 V DC, 1.5 A output. Confirm the adapter and power cord supplied with the specific unit before ordering.

Business Applications

The BaiCells EG2011B-M3 is suitable for indoor broadband deployments where a compatible LTE Band 41 network is available. Potential uses include customer-premises broadband, small-office connectivity, and environments requiring integrated Wi-Fi, Ethernet, and supported telephone connectivity.

Before purchase, confirm regional frequency compatibility, SIM and carrier requirements, service-provider support, and any voice-service requirements.

1. Key Features

• Indoor LTE CPE: Provides broadband data and voice connectivity for compatible LTE networks.

• LTE Band 41: Designed for compatible 2.5 GHz LTE TDD deployments.

• LTE Cat 6/7: Supports the manufacturer's documented Cat 6/7 platform specifications.

• Integrated LTE antenna: Internal omnidirectional antenna with 5 dBi gain.

• Built-in Wi-Fi: Supports 2.4 GHz IEEE 802.11b/g/n wireless networking.

• Gigabit Ethernet: One RJ45 LAN port supports 10/100/1000 Mbps connectivity.

• Telephone connectivity: One RJ11 POTS interface for supported voice services.

• SIM-based access: Supports a 2FF SIM card with 1.8 V/3 V operation.

• Network management: Provides web-based management and documented TR-069 support.

• Compact indoor design: Measures 193 × 168 × 74 mm and weighs approximately 400 g.

2. Technical Specifications

3. Applications / Use Cases

• Indoor LTE broadband access using a compatible Band 41 network.

• Customer-premises connectivity for supported LTE service providers.

• Small-office and home-office internet access.

• Wi-Fi access for laptops, phones, tablets, and other compatible devices.

• Wired Ethernet connectivity for computers and network equipment.

• Supported telephone or VoIP applications.

• Temporary or fixed indoor broadband deployments where LTE coverage and service availability are suitable.

4. Compatibility

The BaiCells EG2011B-M3 is intended for indoor use on compatible LTE TDD Band 41 networks.

• LTE network: Requires an LTE network that supports Band 41 and the device's frequency configuration.

• SIM card: Uses a 2FF SIM. Confirm carrier provisioning, network access, and any SIM-lock restrictions.

• Wi-Fi devices: Compatible with devices supporting 2.4 GHz IEEE 802.11b/g/n Wi-Fi.

• Ethernet devices: The Gigabit Ethernet port connects to compatible RJ45 Ethernet equipment.

• Telephone equipment: The RJ11 POTS port supports only the voice services enabled and provisioned for the device.

• Power: Requires a compatible 12 V DC, 1.5 A supply; verify the included adapter.

• Regional compatibility: Confirm local LTE band availability and regulatory requirements before purchase.

Do not assume compatibility with all LTE operators, all SIM cards, 5G NR networks, or every VoIP provider. The device's supported services depend on the network, carrier configuration, and firmware.

5. What's Included

The exact package contents for the unit being sold have not been confirmed.

The manufacturer datasheet specifies the device's power requirements but does not establish the contents of every retail or distributor package. Verify whether a power adapter, power cord, documentation, and any other accessories are included before publishing a definitive list.

6. Frequently Asked Questions

Q1. What is the BaiCells EG2011B-M3 used for?

It is an indoor LTE CPE device that provides broadband connectivity through a compatible LTE network, with integrated Wi-Fi, Ethernet, and a telephone interface.

Q2. Which LTE band does the EG2011B-M3 support?

The manufacturer identifies this model as a 2.5 GHz Band 41 CPE. Confirm compatibility with the intended carrier and regional frequency allocation.

Q3. Does it have built-in Wi-Fi?

Yes. It supports 2.4 GHz IEEE 802.11b/g/n Wi-Fi, with a manufacturer-listed theoretical maximum of 300 Mbps for 802.11n.

Q4. Does the device have an Ethernet port?

Yes. It has one RJ45 Gigabit Ethernet port supporting 10/100/1000 Mbps.

Q5. Can it connect to a telephone?

The device includes one RJ11 POTS interface. Telephone service depends on supported network provisioning and enabled voice features.

Q6. What is its maximum LTE speed?

The manufacturer datasheet lists up to 220 Mbps downstream and 15 Mbps upstream for a 20 MHz configuration under the specified TDD conditions. Actual speeds vary with network conditions.
