BaiCells EG7010A-M11 Atom OD06H Outdoor LTE Cat 6/7 CPE, 14 dBi, PoE

The BaiCells EG7010A-M11 Atom OD06H is an outdoor LTE CPE designed to provide broadband connectivity for fixed wireless access deployments. It combines an integrated high-gain directional antenna, LTE connectivity, and wired Ethernet in a weather-protected enclosure.

LTE broadband connectivity

The EG7010A-M11 supports LTE TDD and the 3GPP Release 10 Cat 6/7 platform. The manufacturer identifies this model as an outdoor high-gain CPE with support for 3.5 GHz LTE Bands 42, 43, and 48. Its internal directional 2T4R antenna is specified at 14 dBi gain.

The manufacturer lists peak LTE rates of up to 220 Mbps downstream and 15 Mbps upstream under the stated test configuration. Actual throughput depends on network configuration, signal conditions, spectrum availability, and service provisioning.

Gigabit Ethernet and PoE

One RJ45 Gigabit Ethernet interface provides a wired network connection and supports 24 V passive Power over Ethernet. PoE enables power delivery over the Ethernet connection when used with compatible equipment. Confirm the voltage, polarity, pinout, and PoE requirements before connecting the device to a power source.

Outdoor-ready enclosure

The IP67-rated enclosure is designed to provide protection against dust and water ingress under the applicable test conditions. The device supports pole or wall mounting for outdoor installations. Proper mounting, cable sealing, grounding, and installation practices remain important for reliable operation.

Management and configuration

The device supports local and remote web-based management, TR-069 network management, SIM PIN management, and SIM locking. Network functions include NAT, bridge, router, and tunnel modes, with additional configuration and diagnostic capabilities depending on the installed firmware.

Fixed wireless applications

The EG7010A-M11 is intended for outdoor fixed wireless deployments where a compatible LTE network is available. Before purchasing, verify that the specific unit supports the intended operator's frequency band and regional requirements. The manufacturer's listed Wi-Fi-related feature is intended for CPE alignment; do not assume this model provides a general-purpose Wi-Fi access point for end-user devices.

1. Key Features

• Brand: BaiCells

• Model / MPN: EG7010A-M11

• Product family: Atom OD06H outdoor high-gain CPE

• LTE standard: 3GPP Release 10, Cat 6/7

• LTE mode: TDD

• Frequency variant: 3.5 GHz, Bands 42/43/48

• Integrated antenna: Directional, 14 dBi, 2T4R

• Ethernet: One 10/100/1000 Mbps RJ45 interface

• Power: 24 V passive PoE

• Ingress protection: IP67

• Mounting: Pole or wall

• Network management: Local/remote web management and TR-069

• Device dimensions: 248 × 248 × 80 mm (9.8 × 9.8 × 3.2 inches)

• Device weight: Approximately 1.8 kg (4 lb)

2. Technical Specifications

3. Applications / Use Cases

• Outdoor fixed wireless broadband access

• LTE connectivity for rural and remote locations

• Outdoor customer-premises connectivity for compatible LTE networks

• Broadband access for small businesses and distributed sites

• Pole-mounted or wall-mounted LTE installations

• Network deployments requiring a high-gain directional antenna

• Wired Ethernet connectivity for compatible customer-premises equipment

4. Compatibility

Before ordering, verify the following:

• LTE network: The intended operator must support a frequency band compatible with the specific unit.

• Frequency variant: This model is documented as the 3.5 GHz Bands 42/43/48 version. Other customized variants may differ.

• SIM and service: Confirm the correct SIM format, activation, provisioning, and operator acceptance for the actual unit.

• Ethernet: Compatible with RJ45 Ethernet equipment supporting 10/100/1000 Mbps.

• Power: Requires compatible 24 V passive PoE. Do not connect it to a different PoE voltage or standard unless the manufacturer's specifications explicitly permit it.

• Mounting: Suitable for pole or wall installation using compatible mounting hardware.

• Regional compliance: Verify the actual unit's regulatory label and approvals for the intended country.

Carrier compatibility and LTE service availability are not guaranteed solely by the model number.

5. What’s Included

• 1 × BaiCells EG7010A-M11 Outdoor LTE CPE

• 1 × Power Cord

• 1 × PoE Adapter

• 1 × Mounting Bracket

• 1 × User Manual

6. Frequently Asked Questions

Q1. What is the BaiCells EG7010A-M11 used for?

It is an outdoor LTE CPE designed to provide broadband connectivity over compatible LTE TDD networks, particularly for fixed wireless access deployments.

Q2. Which LTE bands does the EG7010A-M11 support?

The documented 3.5 GHz version supports LTE TDD Bands 42, 43, and 48. Customized versions may differ, so verify the actual unit's supported frequencies before ordering.

Q3. What is the antenna gain?

The device has an integrated directional LTE antenna with a manufacturer-specified gain of 14 dBi.

Q4. Does it have a Gigabit Ethernet port?

Yes. It provides one RJ45 Ethernet interface supporting 10/100/1000 Mbps.

Q5. How is the device powered?

It uses 24 V passive PoE. Confirm compatibility with the supplied or separately purchased power equipment before connecting it.

Q6. Can it be installed outdoors?

Yes. Its IP67-rated enclosure is designed for outdoor use, and the device supports pole or wall mounting. Correct installation and cable sealing are still necessary.

Q7. Does it provide Wi-Fi for phones and laptops?

The manufacturer lists Wi-Fi for CPE alignment. Do not assume it functions as a general-purpose Wi-Fi access point for client devices.

Q8. Will it work with any LTE carrier?

No. The operator must support a compatible LTE band, and the device must be accepted and provisioned for the network. Check compatibility before purchasing.
